EVO II Drone // Pro 6K Video

Product Details

• ColorsOrange, Black
• Materials
  Plastic
• Measurements
  11.35"L x 10.5"W x 5.6"H
• OriginUnited States

— Warranty: Manufacturer's 1 Year
— Omnidirectional Obstacle Sensing

Includes
— EVO II Pro Aircraft
— Remote Controller
— 3 Propellers
— Battery Charger
— Power Cable
— RC Charging Cable
— 2 Device Cables
— 1 Battery

Optional Rugged Bundle Also Includes
— 1 Additional Battery (2 Total)
— Carrying Case
— MicroSD Card Holder

Aircraft Specifications
— Takeoff Weight: 1174g
— Unfolded Dimensions: 16.7"L x 13.9"W x 4.3"H
— Folded Dimensions: 9"L x 5.2"W x 4.3"H
— Diagonal Distance: 15.6"
— Max Ascent Speed: 16.4ft/s (Standard Mode); 26.2ft/s (Ludicrous Mode)
— Max Descent Speed: 9.8ft/s (Standard Mode); 13.1ft/s (Ludicrous Mode)
— Max Speed (Near Sea Level, No Wind): 49ft/s (Standard Mode); 65.6ft/s (Ludicrous Mode)
— Max Service Ceiling Above Sea Level: 4.3 Miles
— Max Flight Time (No Wind): 40 Minutes
— Max Hovering Time (No Wind): 35 Minutes
— Max Flight Distance (No Wind): 15.5 Miles
— Max Wind Speed Resistance: Level 8
— Max Tilt Angle: 28° (Standard Mode); 33° (Ludicrous Mode)
— Max Angular Velocity: 120°/s
— Operating Temperatures: 14°F - 104°F
— Operating Frequency: 2.4~2.4835GHz
— Transmission Power (EIRP): ≤26 dBm (FCC, ISED, SRRC); ≤20 dBm (CE, RCM)
— GNSS: GPS/GLONASS/VIO/ATTI
— Hovering Accuracy Range (Vision Positioning Active): ± 0.02m (Vertical & Horizontal)
— Hovering Accuracy Range (With GPS Positioning): ± 0.02m (Vertical); 1.0m (Horizontal)
— Internal Storage: 8GB
— SD Storage: 32 GB (Standard); 256 GB (Max Support)

Camera Specifications
— Sensor: 1" CMOS
— Effective Pixels: 20 Million
— Performance Temperature: 14°F - 140°F
— Lens FOV: About 82°
— 35mm Format Equivalent: 28.6mm @f/2.8
— Aperture: f/2.8-f/11
— Shooting Range: 1m to ∞
— Video ISO Range: ISO100-3200 (Auto); ISO100-6400 (Manual)
— Photo ISO Range: ISO100-3200 (Auto); ISO100-12800 (Manual)
— Electronic Shutter Speed: 8~1/8000s
— Digital Zoom: 1~8x (Max 3x Lossless Zoom)
— Still Image Resolution: 5472*3648 (3:2); 5472*3076 (16:9); 3840*2160 (16:9)
— Still Image Format: JPEG / DNG / JPEG+DNG
— Still Photography Modes: Single Shot, Burst, Auto Exposure Bracketing, Time Lapse, HyperLight, Long Exposure, HDR IMaging
— Video Resolution: 5472*3076 p30/p25/p24; 4800*2700 p60/p50/p48/p30/p25/p24; 3840*2160 p60/p50/p48/p30/p25/p24; 2720*1528 p120/p60/p50/p48/p30/p25/p24; 1920*1080 p120/p60/p50/p48/p30/p25/p24
— Video Format: MOV / MP4
— Codecs: H.264 / H.265
— Max Video Bitrate: 120Mbps
— HDR Video Recording: Support 3840*2160, 2720*1528, 1920*1080
— AE Mode: Auto / Manual / Shutter Priority / IRIS Priority
— AE Measurement: Center Weighted / Spot
— EV Compensation: ±3EV 0.3EV/step
— AWB Mode: Auto / Manual (Sunny / Cloudy / Incandescent / Neon / Custom)
— AF Mode: Auto / Manual
— AF Range: 1m ~ ∞
— Color Mode: None / Black & White / Nostalgic / Log (10-bit)
— Image Style: Standard / Neutral / Landscape / Custom
— Additional Support: PIV Capture, Assist Focus (In MF Mode), Touch AE/AF, AE/AF Lock, Histogram, Defog, ROI

Gimbal Specifications
— Weight: 107g
— Mechanical Range: Pitch: -135~45°, Roll: -45~45°, Yaw: ±100°'
— Controllable Range: Pitch: -90~0°, Yaw: -90~90°
— Stabilization: 3-axis (Tilt, Roll, Pan)
— Max control Speed (Tilt): 200°/s
— Angular Vibration Range: ±0.003° @ 10m/s; ±0.008° @ 15m/s; ±0.013° @ 20m/s

Intelligent Flight Battery Specifications
— Capacity: 7100 mAh
— Voltage: 11.55V
— Max Charging Voltage: 13.2V
— Battery Type: LiPo 3S
— Energy: 82 Wh
— Net Weight: 365g
— Charging Temperature Range: 41°F to 104°F
— Max Charging Power: 82W

Remote Control Specifications
— Operating Frequency: 2.4~2.4835Ghz
— Max Transmission Distance (Unobstructed): 5.6 Miles (FCC); 3.1 Miles (CE)
— Operating Temperature Range: 14°F to 104°F
— Transmission Power (EIRP): ≤26 dBm (FCC, ISED, SRRC); ≤20 dBm (CE, RCM)
— Battery: 5000 mAh
— Weight: 370g
— Operating Current/Voltage: 1.7A@3.7V
— Charging Temperature Range: 32°F to 104°F
— Supported Mobile Device Size: Max 3.3" Width, 0.5" Thick, No Length Limit
— Supported USB Port Types; Lightning, Micro USB (Type-B), USB-C
— Operating Time: 3 Hours
— OLED NITS: 330

Charger Specifications
— Input: 100-240 V, 50/60 Hz, 1.5A
— Output: 3.2 V ⎓ 5 A (Main); 5V⎓3A 9V⎓2A 12V⎓1.5A (USB)
— Voltage: 13.2 ± 0.1 V
— Rated Power: 66 W

App Specifications
— Video Transmission: USB
 —Name: Autel Explorer
— Live View Quality: 720@30fps (Remote Controller); 1080p@30fps (Autel Explorer)
— Latency (Depending On Conditions & Device): 120-130 ms
— Max Live View Bitrate: 40Mbps
— Operating System: iOS & Android

SD Card Support
— Micro SD™; Capacity up to 256 GB; R/W Speed up to UHS-I Speed Grade 3
— 32G Recommended Cards: Sandisk V30, Sandisk Extreme V30 Pro
— 64G Recommended Cards: Sandisk Extreme Pro V30
— 128G Recommended Cards: Sandisk Extreme V30, Sandisk Extreme Pro V30, Kingston Canvas Go!, Kingston Canvas React
